GFP
The multi-phase pump is a combination of a standard centrifugal pump and a liquid ring pump both mounted together on 1 motor and 1 shaft. The centrifugal pump is used for pumping the liquid and brings the main performance of the pump. When a gas-bubble starts to build up in the eye of the centrifugal impeller, it is evacuated by the liquid ring impeller. The pump has 1 suction and 2 discharges: a main discharge of the centrifugal pump and a smaller discharge of the liquid ring pump that functions as an air and foam vent. The air/foam vent is typically connected back to the suction vessel.
-
Properties
Property Max. flow 400 m3/h Differential head 30 m wc Max. Inlet pressure 10 bar Viscosity 1000 cP Max. temperature 140 °C Impeller type Open or closed Max. gas content 30% Max. drive power 45 kW Speed 1800 rpm Available frequency 50 / 60 Hz Materials wetted parts Stainless steel 316L or similar Mechanical seal configuration Single bellow, sterile Available material O-ring EPDM, FKM, FFKM Connections EN1092-1 & ANSI flanges. DIN11851. SMS. RJT. Tri-Clamp Surface finish Electropolished Certificates FDA. EAC -
Description
The multi-phase pump is a combination of a standard centrifugal pump and a liquid ring pump both mounted together on 1 motor and 1 shaft. The centrifugal pump is used for pumping the liquid and brings the main performance of the pump. When a gas-bubble starts to build up in the eye of the centrifugal impeller, it is evacuated by the liquid ring impeller. The pump has 1 suction and 2 discharges: a main discharge of the centrifugal pump and a smaller discharge of the liquid ring pump that functions as an air and foam vent. The air/foam vent is typically connected back to the suction vessel.
Pump series GFP
- Monobloc execution with std IEC motors
- Air vent
- Liquid ring impeller
- Centrifugal impeller
- Clean water inlet
Performance Curves
