FPP2
The food grade Packo stainless steel pumps of the FPP2 series are pumps made of solid, machined stainless steel 316L and are extremely suitable for high system pressure applications up to 40 bar. Typical applications can be found in reverse osmosis applications in all kind of food related applications such as whey filtration, CIP waste filtration, beer filtration, etc.
-
Properties
Property Max. flow 110 m3/h Differential head 110 m wc Max. Inlet pressure 40 bar Viscosity 1000 cP Max. temperature 140 °C Impeller type Open Max. free passage 22 mm Max. drive power 45 kW Speed 3000 / 3600 rpm Available frequency 50 / 60 Hz Materials wetted parts Stainless steel 316L or similar Mechanical seal configuration Single, quench, double Available material O-ring EPDM, FKM, FEP-FKM, FFKM, Silicone Connections Tri-Clamp connections Surface finish Hygienic quality, internal welds hand polished + electropolished Certificates 1935/2004 EC. FDA. EAC -
Description
The food grade Packo stainless steel pumps of the FPP2 series are pumps made of solid, machined stainless steel 316L and are extremely suitable for high system pressure applications up to 40 bar. Typical applications can be found in reverse osmosis applications in all kind of food related applications such as whey filtration, CIP waste filtration, beer filtration, etc.
Pump series FPP2
- Electropolished, easy to clean construction, no bacteria traps and no small clearances in order to clean the area around the O-ring
- Pressed stainless steel in 2B quality plate, extremely smooth
- Large seal cavity to clean mechanical seal properly
- Monobloc execution with std. IEC motors
Application areas
The Packo high pressure pumps of the FPP2 series are used primarily in the reverse osmosis (RO) applications for the filtration of, for example, contaminated CIP-water, whey, etc. They are also used as a booster pump in a variety of skids.
You will find them in just about all industries including the dairy industry, breweries, beverage industry as well as in water treatment industry.
Your benefits
- Suitable for system pressure applications up to 40 bar
- High pump efficiency resulting in lower energy consumption
- Low NPSH values: less risk on cavitation
- Electropolished: easy to clean
- Easy construction and easy maintenance: less downtime
- Standard components
- Easy to install
- 2 seal diameters for the entire range
Performance Curves
