• 性能

    属性
    最大流量 114 l/min
    最大出口压力 6.9 bar
    最大功率 220-240V. 10A. 1 phase. 50/60 Hz
    Liquid connections Center flange DIN DN25/ANSI 1” - end flange DIN DN25/ANSI 1”
    认证 ATEX
    Max. suction lift (wet) 8.8 m wc
    Max. suction lift (dry) 2.4 m wc
    最大颗粒尺寸 3.2 mm
    粘度 10000 MPa
    最高温度 66 °C
    Materials liquids parts Polypropylene, Conductive Polypropylene, Kynar
    Materials valve seats Acetal, Aluminium, Buna-N, Geolast, Polypropylene, Hytrel, Santoprene, Stainless Steel, Viton
    Materials valve balls Acetal, Buna-N, Geolast, Hytrel, Santoprene, Neoprene, Neoprene weighted, Stainless Steel, Viton, PTFE
    Materials diaphragms Buna-N, Geolast, Hytrel, Neoprene (overmolded), Santoprene, PTFE (2 piece), PTFE (Overmolded), Viton
    Material drive section Aluminium, Stainless Steel
  • 描述

    Verderair VA-2E25 非金属电动双隔膜泵是该系列的第二代产品,在具备电动泵的特有优势之外,其同时具有气动泵所有的优点。
